Illumination geometry

D/0°

Illumination light source

Full spectrum LED light source

Spectral Range

400-700nm

Spectral Interval

10nm

Measuring aperture

5mm/14mm

Measurement conditions

Light source D65, field of view 10°; Light source A, field of view 2°; Light source C, fie ld of view 2°

Measuring time

About 3s

Measuring parameter

Haze, Transmittance, CIE Lab, LCh, Yxy, Spectral transmittance, Clarity, Turbidity, Pt-Co(Hazen)

Transmittance resolution

0.01%

Transmittance accuracy

Better than ±1%

Transmittance repeatability

≤0.03 (Measurement condition: the average value of 30 measurements on the whiteboard at an interval of 3s after calibration)

Haze/Clarity resolution

0.01%

Haze/Clarity accuracy

Better than ±2%

Haze/Clarity repeatability

≤0.03 (Measurement condition: the average value of 30 measurements on the whiteboard at an interval of 3s after calibration)

Color repeatability

Standard deviation ΔE*ab is within 0.03 (Measurement condition: the average value of 30 measurements on the whiteboard at an interval of 3s after calibration)

Turbidity resolution

0.1NTU

Turbidity range

0-1000NTU

Turbidity accuracy

≤±(5%H+1NTU), H is standard

Pt-Co resolution

0.1

Pt-Co range

0-1000

Pt-Co accuracy

≤±(5%H+1), H is standard

Power supply

100~277V, 0.4A, 50/60HZ

Display

7 inch 1024*600 dot matrix IPS color screen

Language

Simplified Chinese, English

Data transmission

USB (Type-C)

Operating temperature range

0-45℃， 0-85%RH (no condensation)

Storage temperature range

25-55℃, 0-85%RH (no condensation)

Dimension

211mm×264mm×360mm (LWH)

Weight

5300g

Standard delivery

Main unit, USB cable, power cable, 5mm aperture, screwdrivers
